Watch as we demonstrate the advanced features of the next generation of Scan-RAMs

With the recent launch of the new Scan-RAM 2, Executive Vice President, LabLogic Inc., Victor Tchiprout demonstrates what’s new with the most advanced radio-TLC scanner available for Nuclear Medicine applications. Available in 5 different models combining radio-TLC scanning, radio-HPLC detection, and gamma spectrometry for all Nuclear Medicine applications, Victor talks through the range and their respective features.

New smart detectors for improved counting efficiency

A brand new range of cableless detectors has been introduced with improved sensitivity, including Silicon Photomultipliers, or SiPMs, with Peltier cooling for consistent performance. This delivers up to 50% improvement in counting efficiency for radiochemical purity measurements of 18F-FDG. All detectors are interchangeable and automatically recognised and optimised depending on the radionuclide being used.

18F-FDG radiochromatogram comparing Scan-RAM 1 with PMT/plastic scintillator detector (yellow) to Scan-RAM 2 with SiPM/plastic scintillator detector (green).

A range of configurations

In addition to the standard radio-TLC scanner, Scan-RAM 2 is available in four other configurations that can be paired with different detectors, making it suitable for both high and low levels of radioactivity. In addition to the single-detector TLC scanner, the Scan-RAM 2 is available in four other configurations that can be paired with different detectors, making it suitable for both high and low levels of radioactivity.

A range of configurations

In addition to the standard radio-TLC scanner, Scan-RAM 2 is available in four other configurations that can be paired with different detectors, making it suitable for both high and low levels of radioactivity. In addition to the single-detector TLC scanner, the Scan-RAM 2 is available in four other configurations that can be paired with different detectors, making it suitable for both high and low levels of radioactivity.

If you’re working with a wide range of isotopes, the Scan-RAM 2 Duo has space for two detectors of different scintillator types meaning that the most suitable detector is always available.

The Scan-RAM 2 MCA is ideal if you need to combine radiochemical purity testing and radionuclidic identity combines a multichannel analyser with a dedicated detector into one system.

The Scan-RAM 2 Dual has a single radio-TLC detector and a radio-HPLC detector which operates independently, allowing both analyses to be run simultaneously.

The new Scan-RAM 2 All-in-One combines the functionality of a radio-TLC scanner, a radio HPLC detector, and a gamma spectrometer in one highly flexible system.

Complete a measurement in just 2 clicks with Laura’s new quick start wizard

All Scan-RAMs are controlled by LabLogic’s market-leading software, Laura, which is used in hundreds of radiopharmacies worldwide. The new quick start wizard has an intuitive user interface that simply requires only 2 clicks to complete your run.

Laura has all the features required for regulatory compliance along with many unique features such as a configurable pass-and-fail criteria, automatic peak finder, and half-life correction. It can also be used as a single point of control for HPLCs and GCs from a variety of manufacturers as well as the Hidex range of gamma and scintillation counters.

You can learn more about the new Scan-RAM 2 range by clicking the button below to speak to a product specialist directly and requesting a guided demonstration.
