Features
-
Independent alarm thresholds for both dose and dose rate
-
Automatic calculation of the safe stay time in the Polismart® app
-
Miniature, lightweight design
-
Intuitive single control button
-
Bluetooth integration
-
Wireless charging
-
Optional integration with PM530 or PM531 automated personal dosimetry systems
Specifications
Detector Geiger-Muller tube
Dose indication range 0.01 µSv to 12 Sv
Dose measurement range 1 µSv to 10 Sv
Dose measurement accuracy ± 15 %
Dose rate indication range 0.01 µSv/h to 1.2 Sv/h
Dose rate measurement range 0.1 µSv/h to 1 Sv/h
Dose rate measurement accuracy ± 15 %
Minimum pulse duration of pulsed X-ray radiation 2 ms
Energy range 15 keV to 1.5 MeV
Energy response relative to 0.662 MeV (137Cs) –29 % to +45 %
Alarms visual and audible
Thresholds 2 independent thresholds for both dose and dose rate
Memory 6000 events
PC communication Bluetooth 4.0
Power supply rechargeable battery (wireless charger provided)
Battery lifetime
| with Bluetooth disabled and average dose rate up to 0.3 µSv/h | ≥ 2 months |
| with Bluetooth enabled and average dose rate up to 0.3 µSv/h | ≥ 10 days |
| with Bluetooth enabled and average dose rate up to 1 Sv/h | ≥ 8 hours |
Ingress protection IP67
Drop test 1.5 m
Dimensions 63 × 50 × 18 mm
Weight 50 g
Operating temperature –10 °С to 50 °С
Atmospheric pressure 84 to 106.7 kPa
Humidity 98 % at 35 °С
